Basketball Court Lighting

As a trusted led light manufacturer and expert flood light manufacturer, we proudly present our advanced led system lighting solutions, featuring high-performance tennis court led flood lights and premium sports flood lights outdoor engineered for elite athletic complexes.

Key Specifications & Configuration

• Product Model: LSC-720/800W Stadium Floodlight (Driver-Separated Installation).
• Input Voltage: AC 100–220V, 50/60 Hz.
• Rated Power: 720W / 800W.
• Light Source: Lumileds 5050 LED.
• Power Factor: >0.98.
• Color Rendering Index (CRI): Customizable (CRI 70–90 optional, ensuring athletes and the ball are clearly visible on the court).
• Color Temperature: Customizable color temperature.
• Light Distribution Options: Three or more professional light distribution designs, flexibly meeting diverse court application demands.
• IP Rating: IP66.
• Dimensions: 550 mm × 550 mm × 336 mm.
• Fixture Weight: 18 kg.

Material & Craftsmanship

• Bracket Design: Ultra-tough bracket construction capable of supporting more than 10 times the weight of the lamp body, providing a safety factor higher than industry standards.
• Surface Treatment: The lamp body heatsink undergoes electrostatic powder spraying, offering excellent high-temperature resistance, weather resistance, and rich color options.

Optical & Structural Highlights

• Advanced Optical Design: PC lens arrangement adopts a matrix modular design for high luminous efficacy output. Multi-layer light-blocking rings are designed on the LED lenses to eliminate stray light, effectively reduce spill light, and meet professional visual requirements for stadiums.
• Streamlined Appearance: Features a sleek, streamlined lamp body design that is both aesthetic and professional.
• Advanced Thermal Management: The backside utilizes a fin-type heat dissipation structure for superb thermal performance. An internal sunken design and convection vents optimize airflow quality, enhance cooling efficiency, and fully guarantee the long service life of the fixture.

Electrical & Safety Features

• Power Supply Integration: Features a power configuration with an instant-start function and a power factor above 0.98, ensuring high electrical efficiency, safety, and reliability.
• Protection Grade: IP66 protection level combining a waterproof structural design with a high-resistance silicone waterproof ring for dual protection and enhanced safety.
• Flexible Installation: Equipped with an independent rotating bracket installation system featuring precise scale markings, allowing for arbitrary angle adjustments of the projection direction.
