Tennis Posts&Nets

Looking for premium nets for tennis or a reliable tennis court net replacement? The TN-1012 is an exceptional choice designed for everyday play and standard club use. Whether you are verifying the precise tennis net size for your court layout, replacing a worn-out tennis ball net, or ensuring your facility meets every regulation tennis net standard, this model delivers dependable durability and performance.

TN-1012 Standard Tennis Nets

Key Specifications & Features

• Product Model: TN-1012
• Standard Configuration: Tennis net, steel wire rope, center strap, and center strap anchor (embedded part).
• Material: Crafted from high-quality polyethylene rope, offering excellent resistance to acids and alkalis, anti-aging properties, high impact resistance, and an extended service life.
• Craftsmanship & Edge Binding: Top binding is constructed from PVC material, which is acid- and alkali-resistant with stable chemical properties. The edge binding is reinforced with four layers of dense stitching (machine-made top 6 meshes double-layered, with single-layered construction for the rest).
• Dimensions: Length 12,700 × Width 1,070 mm.
• Mesh Size & Wire Diameter: Mesh size of 44 × 44 mm (±2 mm); wide-edge wire diameter of 3 mm.
• Installation Size Tolerance: Actual physical size tolerance after installation is ±20 mm.
• Color: Black.
• Packaging Details: 1 piece per package.
• Application Scope: Standard tennis courts.

Installation Instructions & Precautions

• Step 1: Attach the retained loop wire rope of the tennis net to the net hook on the “non-crank” secondary tennis post at the opposite side.
• Step 2: Insert the cut loop end of the wire rope into the pulley located under the cap of the main tennis post.
• Step 3: Thread the wire rope through the hole located at the upper section of the gear shaft, allowing 20 to 30 mm of the wire to protrude.
• Step 4: Slowly rotate the crank handle in a clockwise direction to tighten it.
• Step 5: Continue turning the crank handle clockwise to slowly elevate the net to the required standard net height tennis level
